Description

CM-XTF25F Fully Automatic Industrial Washing Machine

• Fully automatic industrial washing machine designed for hospitals, hotels, laundries, and healthcare facilities.
• Microcomputer-controlled system with freely programmable operation and up to 30 customizable washing programs.
• Constructed with high-quality SS304 stainless steel inner and outer drum for durability, hygiene, and corrosion resistance.
• Full suspension shock absorption structure minimizes vibration and noise during operation.
• Supports electric, steam, or hot-water heating options for flexible operation.
• Equipped with imported bearings and high-quality inverter system for reliable performance and stepless speed adjustment.
• Multiple sealing system including oil seal, water seal, and stainless-steel seal for enhanced durability and leakage protection.
• Safety door interlock system improves operational safety and reduces misuse risk.
• External lubrication oil cup for simple maintenance and long service life.

Technical Specifications

1. Wash Capacity: 25 kg
2. Drum Dimension: Φ800 × 500 mm
3. Wash Speed: 48 rpm
4. High Spin Speed: 650 rpm
5. Motor Power: 2.2 kW
6. Inverter Power: 3.7 kW
7. Electric Heater Power: 15 kW
8. Cold/Hot Water Inlet Pipe: Φ20 mm
9. Drain Pipe: Φ60 mm
10. Water Consumption per Cycle: 387 kg
11. Steam Pipe: Φ15 mm
12. Steam Pressure: 0.4 – 0.5 MPa
13. Water Pressure: 0.2 – 0.3 MPa
14. Machine Size: 1090 × 1170 × 1580 mm
15. Weight: 960 kg
16. Outer Cylinder Material: SS304 Stainless Steel
17. Inner Cylinder Material: SS304 Stainless Steel

Features

• Low vibration and low noise operation
• Durable stainless-steel construction
• Easy programming and user-friendly control system
• Energy-efficient inverter technology
• Suitable for continuous heavy-duty laundry applications
• Easy maintenance and long operational lifespan
